Neck Blaster (Gen-2 neck pickup)

Naturally, as the name implies, it is the fully balanced companion pickup for the wonderful Bridge Blaster and it has the sonic character to match.  Lots of thick sounding thump from the low wound strings and noticeably darker sweet plain strings, even in the high register.  It's also good as a companion pickup for PAF type bridge humbuckers and P-90's.

The position 2 sound (bridge + neck) with a Bridge Blaster produces a very nice, strong cluck sound.  It's more intense than the classic Tele B+N sound.

Magnet stagger available only for fretboard radius between 7" and 14" until further notice.  Our amazing Gen-2 neck pickup design together with another Kinman invention which dramatically increases magnetic efficiency allows us to wind a great sounding Zero-Hum neck pickup with incredible loudness, even though it's a small pickup.  We recommend you change to the Technical Tab to the right for important stuff you should know about this new model.



Laser engraved stuff so you won't forget.



Having super high output means at 23mm it's 3mm taller than our original Gen-1 models.  There should not be a problem accommodating it in a modern USA Telecaster.

Exquisite Alnico sound unlike any other and this pickup has Kinman's propriety Alnico low strength magnets, like all our Fender type pickups, so string pull is minimized, sustain is longer and there is less rattle and buzz from the strings crashing into the frets from excessive magnet pull.

Some people will call these noiseless Telecaster pickups but Kinman prefers to describe them correctly as Zero-Hum Telecaster pickups.  That's because there are 2 types of noise, Hum which is cancelled in the pickup and Buzz which can only be minimized by shielding the wiring cavities (refer to >Technical >Perfect Guitar >Shielding for newer guitars

Number of parts in this pickup: 167
Number of parts in normal pickup: 10
Number of parts in other brand noiseless: 23

US Patents  5,668,520  6,103,986  7,022,909  8,791,351


** Alnico-K is a unique proprietary Alnico rod magnet developed by Kinman in 1985.  It is Alnico-5 but has 40% less string pull than Alnico-5 so sustain is longer and there is much less clatter from string crash and no Strat-itis string warble.

* Fender and Telecaster and Tele are registered Trade Marks of Fender Musical Instrument Corp, Inc.  Kinman is not associated with FMIC but they kindly permit us to refer to their Trade Marks to reference our products.

Adjustment requirements

Please refer to >Technical >Adjust & Setup.

Cavity depth required

  • 19mm (3/4").  All Teles except vintage spec models which have 16mm (5/8") and these may require deepening by 2 or 3mm (1/8").

Connection means available

Hook-up cable

  • Prepared and cut generously longer than necessary for Telecasters.
  • Custom lengths by request with Order.
  • 3 conductor shielded cable (OK for series connection of 4 pos switch -and- phase reversible -and- compatible with Fender's S1 harness).

Dimensions

Output Polarity:

  • Phase reversible so can adapt to any companion pickups.

Pot & Capacitor values

  • Best with a 500k volume pot.  Will have subdued piano mid tones and twang with 250k, not recommended.
    • Stock 500k pots can actually measure as low as 350k.  Volume pots in our Goodbye-Soldering Harness are guaranteed to measure no less that 500k and our Gen-2 TK3 and TK4 harness incorporate a switch that changes the pot value from 250k to 500k.
  • Tone pot is usually the same value as the volume but for a little more top end brightness can be 1meg or a No-Load.
  • Normal tone cap value of 0.022uF in 63 ~ 100 volt Polyester.  Smaller value reduces the severity of Treble cut, larger values increase it.

Magnet spread

  • Standard 50mm only.

Magnet Staggers

  • Normal improved Stagger to suit 7 ~ 14 inch uniform radius fretboards.
  • Flat Stagger for specific compound radius fretboards (Warmoth 10 ~ 16 inch and Post 2010 Fender Deluxe 9 ~ 14").
  • Option to specify the magnet stagger of sets and singles in our 'After-Payment' Supplementary Questions' email we send you.

Mounting hardware included

  • 2 Pan head mounting screws 4-40 UNC x 21mm.
  • 2 Silicon Rubber tube springs.

Cover

  • NEW Tele neck pickup can have electro-Chrome, Gold plated or buffed natural Nickel-Silver cover (great for relicing) for extended durability and zero impact on sonic performance.  Matching mounting screws.
  • Arched top to accommodate staggered magnets for perfect string volume balance.
  • With or without Kinman logo.

We highly recommend consulting the Install Guide in Tech Info even if you think you know it all.  Kinmans' require specialized knowledge and sometimes there is updated info.  There is also a handy wiring diagram available.

We also highly recommend consulting the Adjust & Set-up page in Tech Info so you get the best out of your Kinman pickups.

** Alnico-K is a unique proprietary Alnico rod magnet developed by Kinman in 1985.  It is Alnico-5 but has 40% less string pull than Alnico-5 so sustain is longer and there is much less clatter from string crash and no Strat-itis string warble.

* Fender and Telecaster and Tele are registered Trade Marks of Fender Musical Instrument Corp, Inc.  Kinman is not associated with FMIC but they kindly permit us to refer to their Trade Marks to reference our products.
